Body Types and Trim (ACV01)
This lesson explains control valve selection factors and demonstrates
typical linear and rotary control valve functions and applications.
Control valve bodies for several types of valves including globe,
butterfly, and ball valves are described. The function and components of
valve trim, including the relationship between flow characteristic and
trim type is explained.
Modules:
Module Name: Body Types and Trim
